Skat Blast Master Build-Your-Own Trigger Cabinet Kit - 33" Medium Lens

Skat Blast
Skat Blast Master Build-Your-Own Trigger Cabinet Kit - 33" Medium Lens
  • Skat Blast Master Build-Your-Own Trigger Cabinet Kit - 33" Medium Lens
  • Skat Blast Master Build-Your-Own Trigger Cabinet Kit - 33" Medium Lens
Item#
6525-11
MPN#
6525-11
UPC#
728044192344

(0 Rating)
Our Price: $269.00
Zone Map
Zone 1 Zone 2 Zone 3
$45.00 $45.00 $45.00
In-Stock

Your BEST BUY when building your own Sandblast Cabinet - SAVE!

Master Kit includes our Build-Your-Own Trigger Cabinet Kit AND Cabinet Trim Package. These combined kits make it easier than ever to build your own sandblast cabinet!

33" Medium Master Kit includes:
Build-Your-Own Trigger Cabinet Kit:
• S-35 Power Gun - Often mistaken for a pressure blaster when using some of the high-tech abrasives. Bottom of gun has 1/4" female pipe threads for quick connection to 7 ft air hose (included) and 5/8" OD inlet at bottom of siphon head for connection to pickup hose (also included). Includes 1 medium steel nozzle and air jet installed in gun, and 2 extra medium steel nozzles for use with 10-15 cfm air (3 HP minimum - 5 HP is better).
• Siphon Hose is made of clear vinyl so you can see the abrasive flow as it is pulled from funnel of cabinet. Hose is 5/8" inside diameter by 36" long, reaches most areas of the cabinet and can be cut to size.
• Skat Blast Pickup Tube is 27" overall length with mounting hardware. Double-tube design provides a smooth, even flow of abrasive to the power gun. 5/8" OD x 18 gauge.
• 7 Ft Air Hose - High-volume, 3/8" inside diameter. Has 1/4" male brass pipe threads on each end to connect to bottom of power gun and to your incoming air supply of 10-15 cfm.
• Low Air Supply Nozzle Kit includes 3 small steel nozzles, one small air jet, and air jet gasket. This kit enables you to blast with low air consumption (4-8 cfm).
Note: it is necessary to change both nozzle and air jet (both must match when siphon blasting.)
• Build-Your-Own Cabinet Plans - Well-illustrated plans explain how to build a 34" wide x 24" deep cabinet with only two sheets of plywood (plus parts available through our catalog or locally). Adjust dimensions to build a cabinet to fit your needs.
Made in USA.

33" Medium Cabinet Trim Package:
• 12"H x 33"W Tempered Cabinet Lens with outer and inner lenses
• Molded Lens Frame with gasket and screws
• 6051-00 28"L Skat Blast Cabinet Gloves - double strength
• 6057-04 Glove Flanges with screws, clamps, and gaskets
• 6258-03 Floodlight Assembly with gasket, less bulb.

Other items such as trap door, door gasket, hinges, etc are available on our web site, in our catalog, or locally to complete your build. Call for help or assistance.

Your BEST BUY when building your own Sandblast Cabinet - SAVE!

Master Kit includes our Build-Your-Own Trigger Cabinet Kit AND Cabinet Trim Package. These combined kits make it easier than ever to build your own sandblast cabinet!

33" Medium Master Kit includes:
Build-Your-Own Trigger Cabinet Kit:
• S-35 Power Gun - Often mistaken for a pressure blaster when using some of the high-tech abrasives. Bottom of gun has 1/4" female pipe threads for quick connection to 7 ft air hose (included) and 5/8" OD inlet at bottom of siphon head for connection to pickup hose (also included). Includes 1 medium steel nozzle and air jet installed in gun, and 2 extra medium steel nozzles for use with 10-15 cfm air (3 HP minimum - 5 HP is better).
• Siphon Hose is made of clear vinyl so you can see the abrasive flow as it is pulled from funnel of cabinet. Hose is 5/8" inside diameter by 36" long, reaches most areas of the cabinet and can be cut to size.
• Skat Blast Pickup Tube is 27" overall length with mounting hardware. Double-tube design provides a smooth, even flow of abrasive to the power gun. 5/8" OD x 18 gauge.
• 7 Ft Air Hose - High-volume, 3/8" inside diameter. Has 1/4" male brass pipe threads on each end to connect to bottom of power gun and to your incoming air supply of 10-15 cfm.
• Low Air Supply Nozzle Kit includes 3 small steel nozzles, one small air jet, and air jet gasket. This kit enables you to blast with low air consumption (4-8 cfm).
Note: it is necessary to change both nozzle and air jet (both must match when siphon blasting.)
• Build-Your-Own Cabinet Plans - Well-illustrated plans explain how to build a 34" wide x 24" deep cabinet with only two sheets of plywood (plus parts available through our catalog or locally). Adjust dimensions to build a cabinet to fit your needs.
Made in USA.

33" Medium Cabinet Trim Package:
• 12"H x 33"W Tempered Cabinet Lens with outer and inner lenses
• Molded Lens Frame with gasket and screws
• 6051-00 28"L Skat Blast Cabinet Gloves - double strength
• 6057-04 Glove Flanges with screws, clamps, and gaskets
• 6258-03 Floodlight Assembly with gasket, less bulb.

Other items such as trap door, door gasket, hinges, etc are available on our web site, in our catalog, or locally to complete your build. Call for help or assistance.
